Technical Specifications
EtCO2
- MethodNon-dispersive Infrared Spectroscopy
- Range0 - 150mmHg or 0 - 20kPa
- Accuracy±2mmHg or 0 - 20kPa
±5%, range from 41 - 70mmHg
±8%, range from 71 - 100mmHg
- Update timeEvery breath
- Warm up time<15 seconds
- Memory24 hours with trend and numeric
Power
- AC input100V - 240V, 50Hz / 60Hz
- Power consumption5W
- BatteryLithium battery (3.7V, 1400mAh)
- Charging time4 hours via USB
- Operating time6 hours
Respiration Rate
- Range3 - 150 rpm
- Accuracy±1% or ±1 rpm whichever is greater
- Memory24 hours with trend and numeric
- SensorAdapter for intubated patient
Environment
- Operating temperature5 to 40°C
- Operating atmospheric pressure86 - 106kPa
- Operating humidity30% - 75%
- Storage temperature-20 to 55°C
- Storage humidity<93%
- Storage atmospheric pressure50 - 120kPa
Airway Adapter
- TypeAdult / Paediatric, Neonate
- Dead Space5ml (Adult / Paediatric); 1ml (Neonate)
Physical Data
- Dimension38(W) x 42(H) x 44(D) mm
- Weight80g includes battery and adapter
Language
- English / Spanish / Dutch / Italian / French
